User manual / Bedienungsanleitung

3. Set-up

concept active
Setting up the
The turntable chassis, tonearm and cartridge are already assembled and all key parameters have
been pre-adjusted and tested at the Clearaudio factory.
concept active
The turntable needs a set-up space of at least 17 x 14 inches.
1)
concept active
First, take the
the package and place it on a suitable surface.
Then, remove the drive belt from the plastic bag.
2)
Place the drive belt around the sub-platter and
around the motor pulley.
3)
Take the platter out of the package and carefully
place it with both hands onto the shaft.
4)
Carefully remove the adhesive security tape and
further security materials from the tonearm and the
cartridge.
Made in Germany
turntable is easy.
turntable chassis out of
Pic. 2: Placing the turntable
Pic. 3: Placing the drive belt
Pic. 4: Mounting the platter
Pic. 5: Removing the adhesive security tape
5
