1. Hinweise zu dieser Betriebsanleitung 1.1 Pflichten des Die Pflichten des Betreibers des Schließsystems umfassen: Betreibers • Stetiges Verfügbarhalten der Betriebsanleitung für Montage- und Bedienpersonal. • Eine ordnungsgemäße Einweisung im Umgang mit dem Produkt auch für Personen ohne Zugang zur Betriebsanleitung (z. B. Hotelgäste oder Patienten). •...
4. Montage 4.1 Montage- Schließsystem bedingungen Die Komponenten des Schließsystems werden zusammen in einer Verpackung ausgeliefert und sind aufeinander abgestimmt. Komponenten aus verschiedenen Verpackungen sind in Kombination nicht funktionsfähig. Türblatt Geeignete Materialien: Holz, Holzwerkstoffe, Kunststoff und Metall. Einsteckschloss • Einsteckschloss nach DIN 18251. •...
7.2 Schließrechte aller Nach der Löschung aller Benutzerkeys müssen allen gewünschten Benutzerkeys Keys löschen/ wieder Schließrechte zugewiesen werden. Vorgehen bei verlorenem Key Siehe Bild 9 auf Seite 39. 8. Tür öffnen Siehe Bild 10 auf Seite 40. 9. Notöffnung Bei einer Störung muss das Schließsystem von ausgebildetem Fachpersonal (Schlüsseldienst) ausgebaut werden.
11.3 Konformitäts- erklärung Konformitätserklärung Dokument-Nr.: SPX-KE-2014-01-D Hersteller: Sphinx Electronics GmbH & Co KG Anschrift: Tullastr. 3 79341 Kenzingen (Germany) Produktbezeichnung: Elektronischer Profilzylinder Typbezeichnung: DT-510 Hiermit erklären wir, daß das oben aufgeführte Produkt die Bestimmungen der europäischen Richtlinie 1999 / 5 / EU „R&TTE – Richtlinie“ erfüllt.
Seite 8
Operating instructions - English 1. Notes concerning these operating instructions ......9 1.1 Obligations of the operator ................9 1.2 Personnel qualifications ................9 2. Information on the product ............. 9 2.1 Correct purpose of use ................9 2.2 Incorrect purpose of use ................9 2.3 Technical data ...................
1. Notes concerning these operating instructions 1.1 Obligations of the The obligations of the operator of the access control system include: operator • Keeping the operating instructions permanently available to installation and operating personnel. • Providing proper instructions on how to handle the product, also for persons who do not have access to the operating instructions (such as hotel guests or patients) •...
2.3 Technical data DT 510 DT 510 D-DZ Dimensions See figure on page 32 See figure on page 32 Power supply 1 x CR2 2 x CR2 Temperature range of inner and outer -25 – +70°C door knobs Humidity 0 – 95%, non-condensing Protection class max.
4. Installation 4.1 Installation Access control system requirements The components of the access control system are delivered in a package and are coordinated with each other. Components from different packages will not work in combination. Door leaf Suitable materials: Wood, wooden materials, plastic and metal Mortise lock •...
7.2 Clearing the After clearing all user keys, all of the required user keys must have locking locking authorisations assigned to them again. authorisation of all keys/Procedure See figure 9 on page 39. with lost key 8. Open the door See figure 10 on page 40.
11.3 Declaration of conformity Declaration of Conformity Document-No.: SPX-KE-2014-01-E Product Manufacturer: Sphinx Electronics GmbH & Co KG Address: Tullastr. 3 79341 Kenzingen (Germany) Product Designation: Electronic profile cylinder Type Designation: DT-510 We declare that the product mentioned above complies with the regulations of the directive 1999 / 5 / EC “R&TTE –...
Seite 14
Instructions d'utilisation - Français 1. Notes relatives aux présentes Instructions d'utilisation ......15 1.1 Obligations de l'exploitant ................... 15 1.2 Qualification du personnel ..................15 2. Informations relatives au produit ..............15 2.1 Utilisation conforme à l'emploi ..................15 2.2 Utilisation non conforme à l'emploi ................15 2.3 Données techniques ....................
1. Notes relatives aux présentes Instructions d'utilisation 1.1 Obligations de Les obligations de l'exploitant du système de fermeture comprennent : l'exploitant • la disponibilité permanente des instructions d'utilisation pour le personnel de montage et le personnel d'exploitation. • des instructions correctes pour l'utilisation du produit, également pour les personnes n'ayant pas accès aux instructions d'utilisation (p.
4. Montage 4.1 Conditions de Système de fermeture montage Les composants du système de fermeture sont livrés ensemble dans un emballage et sont adaptés les uns aux autres. Les composants provenant de différents embal- lages ne sont pas compatibles entre eux. Feuillure de porte Matériaux adaptés : bois, matériaux dérivés du bois, plastique et métal.
7.2 Effacer les droits de Après effacement de toutes les clés utilisateurs, toutes les clés utilisateurs fermeture de toutes souhaitées doivent de nouveau être attribuées. les clés/Procédure en cas de clé Voir figure 9 à la page 39. perdue 8. Ouvrir la porte Voir figure 10 à...
11.3 Déclaration de conformité Declaration de Conformité Document-No.: SPX-KE-2014-01-F Producteur: Sphinx Electronics GmbH & Co KG Address: Tullastr. 3 79341 Kenzingen (Germany) Désignation du produit: Cilindre eléctronique Type: DT-510 Par la présente nous declarons la conformité du produit dénomme ci-dessus selon les specifications de la directive 1999 / 5 / EC “R&TTE –...
Seite 20
Instrucciones de funcionamiento - Español 1. Notas sobre estas instrucciones de funcionamiento ........21 1.1 Obligaciones del operador ....................21 1.2 Cualificación del personal ....................21 2. Información sobre el producto ................21 2.1 Utilización correcta ......................21 2.2 Utilización incorrecta ......................21 2.3 Datos técnicos ........................
1. Notas sobre estas instrucciones de funcionamiento 1.1 Obligaciones del Las obligaciones del operador incluyen: operador • Mantener siempre las instrucciones de funcionamiento a disposición del personal de montaje y servicio. • Enseñar a manejar correctamente el producto a aquellas personas que no tengan acceso a las instrucciones de funcionamiento (huéspedes, pacientes, etc.).
2.3 Datos técnicos DT 510 DT 510 D-DZ Medidas Vea la ilustración de la Vea la ilustración de la página 32 página 32 Alimentación 1 x CR2 2 x CR2 eléctrica Temperatura ambiente: -25 – +70°C pomo exterior + pomo interior Humedad relativa 0–...
4. Montaje 4.1 Requisitos de Sistema de cierre montaje Los componentes del sistema de cierre se entregan empaquetados en un mismo embalaje y están calibrados para su interacción. La combinación de componentes de diferentes embalajes no funcionará correctamente. Hoja de la puerta Materiales adecuados: Madera, materiales de madera, plástico y metal.
7.2 Cancelar los Después de cancelar los derechos de cierre de todas las llaves de usuario, es derechos de cierre preciso volver a asignar derechos de cierre a las llaves necesarias. de todas las llaves / Procedimiento para Vea la ilustración 9 la página 39. llave perdida 8.
11.3 Declaración de conformidad Declaración de conformidád Documento N°.: SPX-KE-2014-01-S Fabricante: Sphinx Electronics GmbH & Co KG Dirección: Tullastr. 3 79341 Kenzingen (Germany) Denominación del producto: Pomo electronico Denominación del tipo: DT-510 Con este declaramos nosotros que el producto enumerado arriba cumple con las determinaciones de la directriz 1999 / 5 / EC “R&TTE –...
Seite 26
Istruzioni d'uso - Italiano 1. Indicazioni relative alle presenti istruzioni d'uso ........27 1.1 Obblighi del gestore ....................27 1.2 Qualifica del personale ..................... 27 2. Informazioni sul prodotto ................27 2.1 Utilizzo appropriato ....................27 2.2 Utilizzo inappropriato ....................27 2.3 Dati tecnici ........................
1. Indicazioni relative alle presenti istruzioni d'uso 1.1 Obblighi del Gli obblighi del gestore del sistema di controllo accessi comprendono: gestore • La continua tenuta a disposizione delle istruzioni d'uso per il personale addetto al montaggio ed il personale operativo. •...
2.3 Dati tecnici DT 510 DT 510 D-DZ Dimensioni vedi la figura a pagina 32 vedi la figura a pagina 32 Alimentazione 1 x CR2 2 x CR2 Intervallo di variazione della temperatura -25 – +70°C pomello esterno + pomello interno Umidità...
4. Montaggio 4.1 Requisiti di Sistema di controllo accessi montaggio I componenti del sistema di controllo accessi vengono forniti insieme in un imballaggio e sono accordati l'uno all'altro. I componenti di diversi imballaggi in combinazione non funzionano. Battente della porta Materiali adatti: legno, materiali lignei, plastica e metallo.
7.2 Cancellare i diritti di Dopo la cancellazione di tutte le chiavi utente devono venire nuovamente assegnati chiusura / diritti di chiusura a tutte le chiavi utente desiderate. Procedimento in caso di perdita di Vedi la figura 9 da pagina 39. una chiave 8.
11.3 Dichiarazione di conformità Dichiarazione di conformità Documento Nr.: SPX-KE-2014-01-I Produttore: Sphinx Electronics GmbH & Co KG Indirizzo: Tullastr. 3 79341 Kenzingen (Germany) Nome prodotto: Cilindro elettronico Tipo : DT-510 Dichiariamo che il prodotto sopra indicato è conforme ai requisiti della normativa 1999 / 5 / EC “R&TTE –...
