Safety Notes; Use Only As Authorized; Remaining Hazards - Scheppach Woova 3.0 Originalanleitung

• Please pass on safety notes and instruction
• See to it that safety instructions and wamings
attached to the machine are always complete
and perfectly legible.
• Check all power supply lines. Do not use de-
fective lines.
• Insure that the planing machine is set up in a
sta ble position on firm ground.
• Protect the machine from moisture and damp-
ness.
• Keep children away from the machine when it
is connected to the power supply.
• Operating personal must be at least 18 years
of age. Trainees must be at least 16 years of
The machine meets valid EC machine guide-
lines.
• The machine has been built in accordance with
state-of-the-art standards and the recognized
safety rules. Nevertheless, its use may con-
stitue a risk to life and limb of the user or of
third parties,or cause damage to the machine
and to othermaterial proper-ty.
• The machine must only be used in techni-
cally perfect condition in accordance with its
designated use and the instructions set out in
the operating manual, and only by safety-con-
scious persons who are fully aware of the risks
involved in operating the machine. Any func-
tional disorders, especially those affecting the
safety of the machine, should therefore be rec-
tified immediately. The vacuum exhaust unit is
D GB
designed only for removing saw dust (nor for
normal dust).
The machine has been built using modem tech-
nology in accordance with recognized safety
rules. Some remaining hazards, however, may
still exist.
• Wood chips and sawdust can be health haz-
ards. Be sure to wear personal protective gear
such as safety goggles and a dust mask.
• Dust inhalation may occur when closing and
replacing the dust bag. Please note the instruc-
For packaging reasons your Woova 3.0 is de-
livered in semi-assembled state.
Tools required for assembly not included in
shipment
1 Open-end wrench SW 10
1 Open-end wrench SW 17
2 Open-end wrenches SW 13
1 Nut driver SW 8
1 Screwdriver
Assembly frame Fig. A
Axle and wheels
2 lock washers
• Place the wheels onto the wheel axle. Use the
assembly tool and a hammer, and force the
fastening cap on to the wheel axle.

Safety notes

age,but may only operate the machine under
adultsupervision.
• Connection and repair work on the electrical
installation may be camed out by a qualified
electrician only.
• Note the motor rotationat direction – see elec-
trical connection.
• Switch the machine off and pull power supply
plug when rectifying any malfunctions.
• Persons unfamiliar with the machine may not
operate it.
• Perform maintenance tasks, change bag, filter,
orhose only with mains plug unplugged.
• In hazardous locations, only special explosion -

Use only as authorized

• Regularly inspect the filter for damage.
• Replace damaged filters!
• Regularly check that the housing is well sealed
and regularly inspect the filter and saw dust
sackseals.
• Do not allow foreign objects such as screws,
nails, plastic or wood chips to enter the clean-
ing nozzle.
• The machine must only be used with original
parts and orginal accessories supplies by the
manufacturer.
• The Exhaust System woova 3.0 is constructed
exclusively for exhaust-vacuuming wood chips
and saw dust and may only be used in connec-
tion with wood processing machines.
• When vacuuming shop floors, wood or metal
pieces may not be vacuumed.
• Any other use exceeds authorization. The
manufacturer is not responsible for any dam-

Remaining hazards

tions concerning proper disposal in the operat-
ing manual (e.g. the use of P2 dust masks) to
prevent dust inhalation.
• Noise can be a health hazard. The permitted
noise level is exceeded when working. Be sure
to wear personal protective gear such as ear
protection.
• The use of incorrect or damaged mains cables
can lead to injuries caused by electricity.
Assembly
Steering Rollers
2 pan-head screws
2 serrated lockwashers
2 acorn nuts
Frame feet and plate
8 hex screws
8 serrated lockwashers
8 acorn nuts
Fig. B
Screw housing onto frame
4 hex screws
4 serrated lockwashers
Insert filter bag hanger.
10
proof devices may be operated. Use only origi-
nal accessories.
• Verify proper functioning of the machine be-
fore each use.
• Do not use the machine at temperatures below
0 °C, at risk of damaging the housing.
• When leaving the work place, switch the mo-
toroff. Pull the power supply plug.
• Cut off the external power supply of the ma-
chine or plant even if inly minor changes of
place are envisaged. Properly reconnect the
machine to the supply mains before recommis-
sioning.
ages resulting from unauthorized use; risk is
the sole responsibility of the operator.
• The safety, work and maintenance instructions
of the manufacturer as well as the technical
data given in the calibrations and dimensions
must be adhered to.
• Relevant accident prevention regulations and
other, generally recognized safety technical
rules must also be adhered to.
• The machine may only be used, maintained,
and operated by persons familiar with and in-
structed in its operating and procedures. Ar-
bitrary alterations to the machine release the
manufacturer from all responsibiliy for any re-
sulting damages.
• The machine may only be used with original
accessories made by the manufacturer.
• Even when all safety measures are taken,
some remaining hazards which are not yet ....
evident may still be present.
• Remaining hazards can be minimized by fol-
lowing the instructions in "Safety Precau-
tions", "Proper Use" and in the entire operat-
ing manual.
Extractor hose
M10x20 Put hose clamps over hose ends,Insert hose
A10,5
couplings and tighten the hose clamp.
M10 Clamp the extractor hose tightly onto the housing
bracket with hose clamp.
M8x12 Filter bag, Fig. C
A8,2 • Lay locking band (280 mm diameter) on hous-
M8 ing.
• Fit filter bag over housing collar and fasten
with locking band.
M8 x 12 Sawdust bag, Fig. D
A8,2 • Open clamping lug.
• Fit sawdust bag over ejection opening, fold at
clamp recess and close clamping lug.
• Lay locking band (337 mm diameter) over
sawdust bag and fasten.
