Operating lights:
(15)
(16)
DESCALE
(1) Steam shot button
(2) Steam button
(3) Temperature control dial
(4) Iron setting light
(5) Soleplate
(6) Thermal rest
(7) Unlock button
(8) Cable guide
(9) On/Off button
(10) Arrow buttons
(11) Water tank
Controls and appliance parts
(17)
(18)
(20)
(19)
(12) Locking mechanism for the
water tank
(13) Tank cap
(14) Locking bolt
(15) Indicator light
(16) Descale light
(17) Refill light
(18) Low-steam light
(19) Medium-steam light
(20) High-steam light
(21) Screw plate
(22) Water drain plug
