INFO ONSCREEN DISPLAY
Press i button on remote control to display channel information, showing other SSID device in
the area. It shows signal strength and Wifi congestion to help trouble-shoot.
Note: To show all SSID in range the Rx must not be "connected" to any Tx when you do this.
Change the Rx channel to an unused channel first.
Note: if you are having problems and need to Contact Us via
send a photo of the information on this screen.
RS-232
Baud rate: 115 200
Command
Channel 0
Channel 1
Channel 2
Channel 3
Channel 4
Channel 5
Channel 6
Channel 7
Channel 8
Channel 9
ASCII
rxch:00
rxch:01
rxch:02
rxch:03
rxch:04
rxch:05
rxch:06
rxch:07
rxch:08
rxch:09
www.visionaudiovisual.com
HEX
72 78 63 68 3a 30 30
72 78 63 68 3a 30 31
72 78 63 68 3a 30 32
72 78 63 68 3a 30 33
72 78 63 68 3a 30 34
72 78 63 68 3a 30 35
72 78 63 68 3a 30 36
73 78 63 68 3a 30 37
74 78 63 68 3a 30 38
75 78 63 68 3a 30 39
please
