Connectors and connections

The installation must be carried out only by qualified technical staff: an improper connection of the peripheral
units may cause the keyboard to be isolated from the rest of the system.

Installation example

Installation controlled by one operator with one monitor: the operator controls one pan & tilt motor and the following
telecamera functions FOCUS, ZOOM, DIAPHRAGM (IRIS):
Installation example
One operator with more monitors, who controls a series of pan & tilt motors in mixed configuration (star and cascade
connection)
DTRX
DTMRX
DCS2
7 wires-cable for the
control of the P&T head
CBZ230/CBZ24
DTRX DTRX
DCMX
MATERIAL USED
Control keyboard:
•
Video handling:
•
•
•
•
•
•
•
SW16.4 OSM
Pag. 6
MATERIAL USED
Control keyboard:
•
1 CBZ230/CBZ24 control keyboard
Video handling:
•
1 monitor
Telemetry handling:
•
PTH910 / PTH911 - PHH810 /
1
PHH811
pan & tilt motor
•
1 motorized zoom lens
1 DCS2 control keyboard
1 SW16.4 OSM video switcher
2 monitors
4 telecameras
Telemetry handling:
1 DCMX serial data multiplexer
4 DTRX receivers
PTH910 / PTH911-PHH810 / PHH811
4
tilt motors
PTH910 / PTH911 - PHH810 / PHH8119825
pan &
