For maximum accuracy, the conductor must be
7.
located in the centre of this area during
measurement.
MAX button (CM600 and CM610): this shows the
8.
maximum value, automatically updated, for the
when the function is activated: pressing it again
cancels the function.
SELECT button.
9.
CM600 and CM610: Alternately selects diode test
CM625: Alternately selects measurement of:
- the DC current or reset (40 ADC range);
- the resistance or continuity test
10.
Red positive terminal (+).
11.
CM625: indicates the clamp's orientation.
12.
HOLD button (CM625)
This holds the measurement (Data Hold); the
icon appears when the function is activated. Pressing
the button again cancels the function. Automatic
shutdown AUTO POWER OFF (25) is deactivated in
this mode.
6.2 THE DISPLAY
No. Function
Continuity
13.
Negative value
14.
AC
15.
DC
16.
Low batteries
17.
Max. value
18.
Diode test
19.
6.3 THE REAR FACE
No. Function
Safety text
27.
7.1 TO USE THE CLAMP-ON METER
Set the selector (3) to any position other than OFF.
7.2 TO STOP THE CLAMP-ON METER
Set the selector (3) to OFF.
Automatic shutdown
The multimeter shuts down automatically 10 minutes after the
last measurement; the buzzer sounds one minute before
shutdown. Pressing any button except SELECT restarts the
multimeter.
Cancelling automatic shutdown (CM625 only)
1. Set the selector (3) to OFF.
2. Hold down the HOLD button and set the selector (3) to
any position other than OFF.
The AUTO POWER OFF icon disappears and automatic
shutdown is deactivated.
functions. The
or continuity test .
No.
20.
21.
22.
23.
24.
25.
No.
28.
7. USE
13
icon is displayed
.
Function
Resistance
Current voltage
Max. value
Auto ranges
Hold value
Auto shutdown
CM625 only
Function
Battery compartment
