Electrical connections
• Connect the appliance to a 230 V ~ 50 Hz socket-
outlet with earthing contact. Minimum fuse 10 am-
pere.
• The appliance is switched on and off using the integ-
rated ON/OFF switch.
• A built-in thermostat protects the motor from over-
loading and blocking. The pump is switched off au-
tomatically by the thermostat if overheating occurs
and is switched on again automatically after cooling.
Operation
• Install the equipment on a solid and level surface.
•
screw (3). Filling the intake line accelerates the in-
take process.
• Assemble in reverse order.
• Open the discharge line.
• Connect the mains cable.
• Switch on the equipment with the power switch (5) -
water can be suctioned in for up to 5 minutes (maxi-
mum suction height).
• The unit turns itself off when the deactivating pressure
of 3 bar is reached.
• When the pressure decreases owing to water con-
sumption, the machine turns on automatically (acti-
vating pressure approx. 1.5 bar).
• The house water system can also be permanently in-
stalled indoors to be used as the house water supply.
In order to minimise vibrations and noise, the pump
hose lines. Placing anti-vibration material, such as a
rubber layer, between the pump and its base is also
recommended. Ensure secure fastening of the contai-

Replacing the power cable

If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its aftersales
service or similarly trained personnel to avoid danger.
Cleaning, maintenance
The equipment is almost completely maintenance
free. In order to ensure a long service life, however,
we recommend that you regularly check and care for
the product.
Important!
The equipment must be disconnected from the power
supply (pull the power plug) prior to performing any
maintenance.
Servicing
• If the equipment becomes clogged, connect the
discharge line to the water line and disconnect the
suction hose. Open the water line. Switch on the
equipment several times for approx. two seconds.
This should resolve the majority of clog-related pro-
blems.
12 GB
• The pressure in the pressure container should be
a maximum of about 1.5 bar. If the air pressure is
too low, it should be increased. For this, unscrew
the valve cover (Fig. 3/No.10) on the container and
make up the missing pressure via the valve (No. 11)
using a tyre pump. Replace the valve cover after-
wards.
• Replacing the mains cable: Important:
Disconnect the equipment from the power supply!
A defective mains cable may only be replaced by a
• There are no parts inside the equipment which re-
quire additional maintenance.
Storage
• If the pump is not going to be used for a long
time or has to be removed for the winter months,
rinse it out with water, empty it completely and
allow it to dry.
• The equipment must be completely drained before
it is subjected to frost.
• After long stoppages, make sure the rotor turns cor-
Storing
Store the device in a dry place beyond the reach of
children. When the device is not being used, store it so it
cannot be started by unauthorised persons.
WARNING!
Do not store the device without protection outside or in a
damp environment.
Frost destroys the appliance and accessories, as
these always contain water!

Disposal and recycling

The equipment is supplied in packaging to prevent it
from being damaged in transit. The raw materials in this
packaging can be reused or recycled. The equipment
and its accessories are made of various types of material,
such as metal and plastic. Defective components must
be disposed of as special waste. Ask your dealer or your
local council.
