Connecting Peripheral Devices

Don't use force when
connecting plugs
– otherwise you may
damage the plugs or
connectors.
If the monitor is not
able to process the
frequencies from the
graphics card, it could
be destroyed!
MAXDATA Workstation FUSION 1000

Connecting a Monitor

Any monitor which complies with the VGA graphics standard
can be connected to your workstation. The connection socket
for the monitor is located on the rear side of your workstation
and is marked with a monitor symbol.
If you use an older monitor, carefully compare the technical
data of the monitor and the graphics card.
The workstation and the monitor must be switched off
when being connected, as otherwise the hardware may be
damaged.
Connect the plug from your monitor to the 15-pin VGA con-
nector of the graphics card of your workstation.
Connect the monitor power cable to a grounded outlet.
