Radio Frequencies for Units with Wireless LAN

The following information was correct at January 2002. You can obtain current information
from the appropriate authorities in your country (e.g. www.regtp.de).

Frequencies

Radio network cards and adapters are designed in accordance with IEEE-Standard
802.11b+g for use in the ISM frequency band (Industrial, Scientific, Medical) between 2.4
and 2.4835 GHz. Because of the DSSS-procedure (Direct Sequence Spread Spectrum), each
of the 11 usable radio channels takes up a width of 22 MHz; this means that up to three,
independent channels are available (e.g. 3, 8 and 11). The following table lists the authorised
channels in your country:
Channel MHz
1 2412
2 2417
2422
3
4 2427
5 2432
6 2437
7 2442
8 2447
9 2452
10 2457
11 2462
In addition, the integrated radio network card supports the 802.11a standard.
For more information pertaining to the 5 GHz band frequencies authorized in your country,
please contact the appropriate supervising authority.
MAXDATA Workstation FUSION 1000
Europe, R&TTE France, R&TTE
X
X
X
X
X
X
X
X
X
X
X
X
X
UK
63
