10 Feed the harness straps (i) through the shoulder pads (ii).
Thread the harness straps and shoulder pad straps through the holes in the headrest to the
11
back of the seat ensuring all straps are at the same height. Connect the two shoulder pad
straps using the Velcro®.
Reconnect the harness straps to the yoke.
12
IMPORTANT! Make sure the harness straps pass through the same hole height positions on
13
the headrest and the seat. IMPORTANT! Ensure the harness is routed between the seat and
the support leg. The harness MUST NOT pass over the support leg' s horizontal bar (i).
14
Make sure the height is correct by placing your child in the seat.
WARNING! Never use this child seat without the shoulder pads. The shoulder pads are an
important safety feature.
Positioning the child restraint
The easiest way to lift the Move into the vehicle is with its back first. Place the child restraint in
15
the vehicle with the back of the restraint facing the front of the vehicle.
The heels (I) should be sitting over the edge of the vehicle seat. The indented vertical line (J) on
16
the heel should align vertically with the end of the vehicle' s seat. If installing in a small vehicle, or
if your child does not require extra leg room, you can instead place the heel upon the vehicle' s
seat this will also achieve a more reclined position.
Note: When installing Move in the front seat it is possible, but not crucial, for the back of the restraint
to have contact with the dashboard.
To adjust the angle of the child restraint, rotate block (G) into one of the two tilt positions. Always
17
choose the most upright position as possible, however your child must be able to hold their
head up on its own, and there should be enough recline to ensure your child' s head does not fall
forward when sleeping. The rule of thumb is that the older the child grows, the more upright the seat
can be installed. Please note that once the installation of the Move is complete, it will be somewhat
more reclined as it sinks into the vehicle' s seat from tightening seat belts and tether straps.
Never install a child restraint in a passenger seat
where an active airbag is fitted.
