technIcal data

Power supply
switching current
Protection type
Protection class
switching time
permissible
temperature range
Power reserve
accuracy
standby consumption*
mounting type
*The clock is always ready for operation to execute the set switching
times and additional functions.
230 v ac / 50 hz
3a / 230 vac inductive load
IP 20
II after the respective installation
180 seconds
0° c to 50° c
approx. 5 hours
approx. +/- 1 seconds / day
1.5 watts
flush mount wall box, Ø 60 mm,
hole spacing, min. 25 mm depth
on-wall mountable with correspon-
ding housing
