Cover
Substitution/maintenance
Detach the protection panel of the flat cable from
the rear of the cover.
To reach the electronic keyboard unscrew the two
screws shown in the figure.
Detach the cover from the electronic keyboard by
pushing outwards the two retaining wings shown
by the arrows in the figure.
Front part maintenance
