Front part maintenance
GB
32
To extract the frame from its seat remove the
pod drawer and unscrew the two screws shown in
the figure.
Unhook the frame lifting it upwards and outwards.
Unscrew the fixing screw situated inside the hole
indicated in the figure and remove the fitting from
the left side, sliding it upwards.
