Product Specifications

Rotary Hammer
Article number
Speed control
Rotation stop
Right/Left rotation
Quick change drill chuck
Rated input power
Impact rate at nominal rotational speed
Impact energy per stroke
Nominal speed
Right rotation
Left rotation
No load speed
SDS-plus tool holder
Spindle collar diameter
Maximum drill diameter:
Masonry (core drill)
Concrete
Wood
Steel
Weight in accordance with EPTA-Procedure 01/2003
Protection class
Auxiliary Handle (see Fig.
Operate the machine only with the auxiliary handle 14.
By rotating the auxiliary handle 14 to a comfortable po-
sition, a fatigue-free and therefore safe working posi-
tion can be achieved.
Loosen the auxiliary handle 14 in the counter clock-
wise direction and adjust the handle to the desired
working position. Ensure that the clamping band of the
auxiliary handle is located in the groove intended for it
in the housing.
Then retighten the auxiliary handle 14 by turning in the
clockwise direction.
1 619 929 704 • (05.06) T
4 OPERATING INSTRUCTIONS
)
A
English–4
BTI-BH 2-26 ME BTI-BH 2-26 MES
9001329
[W]
[per min] 0 ... 4000
[J]
[RPM] 0 ... 900
[RPM] 0 ... 900
[RPM]
[mm]
[mm]
[mm]
[mm]
[mm]
[kg]
Selecting Drill Chucks and Tools
For hammer drilling and chiselling, SDS-plus tools are
required that are inserted in a SDS-plus drill chuck.
For drilling in steel or wood, for screw driving and for
thread cutting, tools without SDS-plus are used (for
example, drills with cylindrical shafts). For these tools,
a quick change keyless or a ring gear drill chuck is re-
quired.
Do not use tools without SDS-plus for hammer
drilling or chiselling! Tools without SDS-plus and
their drill chucks are damaged by hammer drilling or
chiselling.
BTI-BH 2-26 MES: The SDS-plus quick change drill
chuck can be easily replaced with the keyless drill
chuck provided.
9001330
●
●
●
–
800 800
0 ... 4000
3.0
0 ... 900
0 ... 900
1300 1300
●
50
68
26
30
13
2.7
/
●
●
●
●
3.0
●
50
68
26
30
13
2.9
/
