13 Erläuterungen
13.1 NAV BOX Einstellungsmöglichkeiten und Bedeutung
Item
Above ground level
Air temperature
Altitude IGC
Altitude QFE
Altitude GPS
Altitude QNH
Altitude QNH (ft)
Analog clock
Arrival altitude
Average vario
Average netto vario
Battery
Bearing TP/APT/T
Compassheading
Cur. eff. TP/APT/TSK
Digital clock
Dist. to sel. TP/APT
Empty
ETA (averagespeed)
ETA (currentspeed)....
ETA MacCreadyspeed
Final glide
Final glide (MC 0.0)
Flight level
Flying time
GPS position
GPS signal
Ground speed
Horizonatl distance from
airspace
Hardware
Indicated Air Speed
Leg speed
Netto vario
OLC
OLC home
OLC speed
Off course distance
Radial TP/APT
Recommended flaps
position
Relative vario
ETE – estimated time
enroute
Rem. T. to TP/APT/TSK
Requiredeff. TP/APT.....
LX Zeus v 3.. 5.8.2014
Description
Altitude above ground level
OAT
Altitude recorded by flight recorder (1013 based)
QFE altitude based on approaching point
Altitude recorded by GPS
Altitude over sea level
Altitude over sea level in ft
Analog clock symbol
AGL height (+reserve) on arrival at selected TP
Integrator (average of last x seconds – set in SETUP /
VARIO SC / Integration scale)
Average of air mass vertical movement during the whole
flight
Battery symbol
Bearing to TP/APT or TP of task
Heading that is calculated from compass (if compass
module is installed)
Efficiency calculated during last time period
Digital clock symbol
Distance to TP/APT
NAV BOX will remain empty
ETA based on average sped reached
Estimate time of arrival based on actual speed
ETA based on MC setting
Altitude difference regarding to f.g. line
Altitude difference regarding to f.g. line at MC 0,0
Actual flight levelindication
Time spent in the air
Indication of coordinates
GPS status symbol
Speed over ground
Glider position horizontally from the airspace
HW status connected to Zeus
Airspeed not altitude corrected
Leg speed on task
Shows air mass vertical movement
Olc point scored to current location
Olc points that will be scored if takeoff position is
reached.
Speed when flying a cross country flight under the rules
of OLC
Off course indicator
Radial from TP/APT to the glider position
Recommendes flaps at pre-set speed range
Netto vario – 0,7
Remaining time to selected TP/APT or until end of Task
Remaining time to selected TP/APT or until end of TSK
Required efficiency to reach TP/APT/TSK
NAV
BOXdesignator
AGL
Temp
Alt IGC
Alt QFE
GPS Alt
Alt QNH
Alt QNH
Clocksymbol
Arri Alt
V Avg
AVG netto
Batterysymbol
BRG
HDG
E
Time
Dist
Nodesignator
ETA Avg
ETA Sp
ETA MC
FG
FG(MC 0,0)
FL
Flying
Coordinates
GPS Symbol
GS
AS hor
Active HW
IAS
Leg speed
V Netto
OLC
OLC Home
OLC sp
Off co
QDR
Flaps
V relative
ETE
T to TP
Req E
