UNITS PARTS
Front Panel
Louver
Air filter
(pull it out)
NOTE ON ILLUSTRATIONS
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be
slightly different. The actual shape shall prevail.
Wall Mounting Plate
Fig.3.1
Drainage Pipe
Remote Control
74
3
Signal Cable
Refrigerant Piping
Remote Holder
Power Cable
