5. Mounting the camera
26
Now place the camera attached to the plates into panorama head with the
lens pointing downwards (see Fig . 6) . Push the slide rail past the resistance of
the saftey lock into the desired positions and secure the rail using the screw
the side .
To positions the camera in
the vertical plane loosen
screw "W" on the back (see
Fig 6) . Pivot the camera to
the desired alignment and fix
tightening screw "W" .
The position of mount "M" on rail
"F" is adjusted as follows loosen:
Screw "O" and slide the mount along
the rail . The ideal positioning is to place
the camera bidy on the rail "N" as far
back as possible, as the mount at "F"
that this rail does not appear in the
it in this position by
must be in such a position
camera´s field of view "P" .
ENGLISH
W
F
1
Fig . 6
P
N
Fig . 7
2
F
M
O
