5
DMX OutPut
Female, 3-pole XLR socket. Used to loop through the DMX signal to additional DMX devices.
6
inPut FOR FOOt PEDAl
Female, 5-pole XLR socket for connecting the optional foot pedal. The socket delivers the supply voltage for
the footswitch, so it must always be connected using a 5-pole DMX cable with all signals connected.
7
MiCROPhOnE FOR MuSiC COntROl.
8
lit lC DiSPlAY With 4 COntROl ButtOnS
See the following pages of the User Manual.
9
POWER Out 1 AnD 2
Separate power sockets, switchable via DMX, infrared remote control, and optional footswitch, for powering
additional CAMEO lighting products. Make certain that the power consumption of the connected devices does
not exceed 3 amperes.
10
MOuntS 1 AnD 2
Moveable mount for mounting up to 2 additional lights, for example, the CAMEO CLMOVER1. The weight of
the lights to be mounted must not exceed 5 kg each.
IMPORTANT INFORMATION: When mounting one or two additional lights, make certain that the overall construction
is not overweighted on one side (balanced distribution of weight) and that the maximum load of the stand used is
not exceeded! For mounting, please use only the included mounting bolts.
11
POWER SuPPlY CABlE FOR SPOtlightS 1 tO 4
12
ADjuSting SCREWS
Using the adjusting screws A and B, each of the 4 lights can be adjusted separately both horizontally and vertically.
13
inFRARED intERFACE
In "IR ACTIVE" mode, this interface on the front of the multi PAR lighting system is used to control the unit
with the included infrared remote control. Make certain that there is a direct line of sight between the infrared
interface of the remote control and the infrared interface of the multi PAR lighting system.
14
inDiCAtOR lED
As soon as a control command is given via the IR remote control, the indicator LED flashes.
COntROlS AnD DiSPlAY:
9
