C.A.S. II installation manual
4.2 Technical specifications
Supply voltage:
Current consumption:
Assignable transmitters max:
Transmitter frequency:
Transmitting power:
Range max:
Average battery life:
Battery type (transmitter):
Battery type central unit:
Number of codes:
Temperature range:
Temperature range, self-adhesive pad: -15° to + 80°C
4.3 Conformity
4.4 Maintenance instructions
The battery life of the basic rechargeable battery (Item no: THZ-1-00006) is
approx. 1000 charge cycles or approx. 3 years. If the base housing is opened
for the purpose of inspection, replacement or some other purpose after
more than 2 years, the gasket set (Item no. THZ-1-00007) must be replaced
otherwise the base can no longer be guaranteed to be leakproof.
4.5 Disposal instructions
When the unit is no longer in use, please do not dispose of it
with household waste. Municipal recycling centres have suitable
containers for the disposal of electronic equipment.
Take the packaging materials to the recycling centre.
In order to assist you more accurately with any technical support which may
be necessary, please enter the serial number of the unit here. You will find
the serial number on the underside of the bottom of the unit.
Serial number of the unit:
This alarm system complies with the requirements
of the EMC directive 2004/108/EC
_ _ - _ _ _ _ _
SN
12 V
approx. 25 mA without GSM/GPS Combimodule
approx. 35 mA with GSM/GPS Combimodule
99
868,35 MHz
<10 mW
up to 100 m in the open
2 years
CR2032 (button cell/3 V)
Rechargeable NimH 7.2 V/1500 mAh
<4 billion. (<4,000,000,000)
-10° to + 80°C
