C.A.S. II operating instructions
2.1 Using the GSM/GPS Combimodule (optional)
If a GSM/GPS Combimodule (Item no: THA-2-00027) has been
connected, there are numerous additional functions and alarm
options available.
– Alarm message if there is a break-in, gas or, if the cable loop is triggered,
with information on the type of incident, time of incident, position and speed.
– Site monitoring (Geofencing): If the vehicle leaves the original site
beyond a radius of 1 km when the system is activated (as the crow
flies, +/- 0.5 km), a theft signal will be transmitted after a maximum
of 2 minutes. In order to pursue the vehicle, status messages can be
requested as required.
– Status enquiries: If you want to enquire after the whereabouts of the
vehicle or the state of the alarm system (armed or unarmed), you can
request status messages at any time.
– Can be armed or disarmed via SMS or phone call at any time.
After switching successfully, you receive back a status message*
with the current state of the system.
*depending on the setting on the program selector switch
– You receive tamper messages if, when the system is activated, an
interfering transmitter blocks the frequency of the alarm system for
more than 5 seconds, the supply voltage is interrupted or the alarm
system is opened.
– Warning messages will be sent to you if the vehicle battery voltage drops
below 11.8 V while the system is armed. The SMS then says "switch to
battery mode". If the rechargeable battery voltage drops to a critical level,
a "Battery low" SMS will be sent and the alarm system switched off (when
the battery is fully charged, this happens after approx. 36 hours).
– Master numbers are target phone numbers which not only receive alarm
SMS and status messages but are also authorised to arm and disarm the C.A.S..
Example alarm message in the event of a break-in
Break-in door/window
Status: armed
UTC: 14:09:11
POS: 55 23.7468'N
011 10.3217'E
Reception: - 53 dB
Menu
from: ALARM
Back
< Reason for message
< State of alarm system
< Time of incident (coordinated universal time)
< Position of vehicle
< Reception quality of mobile phone
- 99 dB to - 75 dB
- 75 dB to - 50 dB
- 49 dB to - 39 dB
- 38 dB
Page 7
very good
good
satisfactory
poor
