8 Operation
On the primary side several components of the secondary side with the same configuration can also be operated
(so-called Dynamic Pairing). With power on the primary side a startup delay of 10 ms must be expected.
9 Troubleshooting
9.1 Rectifying Ambient Interference
The device is provided with an FOD function (Foreign Object Detection). The FOD detects metal foreign objects
in the active area between the primary and secondary side. The device then automatically switches off the power
supply. The FOD status is indicated as follows:
Device
NICP-M30-IOL2P8X-H1141
NICP-M30-8P8X-0,3-RSC12T
Once the device detects no more metal, the system automatically returns to the operating mode.
9.2 Rectifying Device Faults
If the device does not function as expected, first check whether ambient interference is present.
If this is not the case, a device fault is present. In this case, decommission the device and replace it with a new
device of the same type.
10

Maintenance

The devices are maintenance-free.
The active area between the primary side and the secondary side must be cleared occasionally of any metal con-
tamination (e.g. chips) in order to improve operation.
11

Repair

The device must not be repaired by the user. If the device is faulty, decommission it and send it to TURCK. Observe
here the specific warranty conditions agreed with the shipment.
12

Decommissioning

Remove the connection cable from the power supply and/or sensing devices.
➤ ➤
Remove the connection cable from the primary side.
➤ ➤
Remove the connection cable from the secondary side.
➤ ➤
Undo the connections of the device or if necessary the mounting aid for the mounting area.
➤ ➤
Undo if necessary the connection of the device to the mounting aid.
➤ ➤
13

Returning The Devices

If a device has to be returned, bear in mind that only devices with a decontamination declaration will be accepted.
This is available for download at
http://http://www.turck.de/static/media/downloads/01_Declaration_of_decontamination_EN.pdf
and must be completely filled in, and affixed securely and weather-proof to the outside of the packaging.
14

Disposal

These devices are designed for installation in fixed industrial installations and equipment, which must be disposed
of in accordance with the laws and regulations applicable to these installations. They must not be included in
normal household garbage.
more@turck.com • www.turck.com • 2015/04
FOD active
LED flashes at a frequency of 1 Hz.
FOD status contact is set.
Operation
