Technical Specifications - Simons Voss Technologies PinCode Online Kurzanleitung

9 Technical specifications

PIN code keypad
Batteries:
Battery life:
Dimensions in mm:
Protection class:
Operating temperature:
Signal elements:
Marking:
Housing:
Main colour:
Key labelling:
44
4 x 3 V lithium, type CR 2032 (Sony,
Panasonic, Varta)
Always replace all four batteries with
new, approved, brand-name batteries
when changing them.
up to 500,000 lock operations or up to 12
years on standby
96 x 96 x 14
IP65
-20 °C to +50 °C
Different colour LEDs (red, green, or-
ange) + audible signals
PHI number (physical hardware identi-
fier) = chipID
Silver ABS polymer housing with semi-
transparent rear/base plate
Similar to RAL 9007, using formula no.
19900841
RAL 7016 Anthracite Grey
SimonsVoss Technologies GmbH
