6. Technical data

LB5200BP
Technical data
Dimension LxWxH mm
Air speed max. km/h
air volume max. m /min
3
dust bag capacity l
Power unit
Displacement cm
3
Max. engine output kW
Idle speed min
-1
Fuel tank capicity cm
3
Engine type 2-stroke engine, air-cooled
Weight kg
Subject to technical changes!
Information concerning noise
according to relevant standards:
Sound pressure L = 94,0 dB(A)
pA
Sound power L = 110 dB(A)
WA
Uncertainty K = 3 dB(A)
PA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Vibration A = 1,655 m/s
2
hv
Uncertainty K = 1.5 m/s
2
PA
Reduce noise generation and vibration to a minimum!
• Use only equipment that is in perfect condition.
• Maintain and clean the equipment regularly.
• Adopt your way of working to the equipment.
• Do not overload the equipment.
• Have the equipment checked if necessary.
• Switch off the equipment when not in use.
• Wear gloves.
In these operating instructions we have marked the
places that have to do with your safety with this sign:

7. Attachment and operation

ATTENTION! Before working on the device - cleaning,
inspection, maintenance or other work - always turn off
the device.
ASSEMBLY
The blower must not be used or switched on until
it has been fully assembled.
Assembly (Fig6-6c)
• Attach the two hose clamps (17A and 17B) to the fle-
xible blowpipe (12).
• Push the flexible blowpipe (12) over the connection to
the motor unit and tighten the hose clamp (17B) firmly
(Fig. 6).
• Now push the handle (1) over the upper blowpipe (13).
Align the handgrip (1) and the guide in the same way,
fold it together and then tighten it (Fig. 6a).
1380x400x450
295
18
-
51,7
1,4
3500 ± 300
1000
7,84
emission measured
• Push the upper blowpipe into the flexible blow hose
(12) with the handle and fix it with the hose clamp (17A)
(Fig. 6b).
• Push the lower blowpipe (14) over the upper blowpipe
(13) and lock it in the clockwise direction (Fig. 6c)
• The blower nozzle (No. 15) is simply pushed over the
lower blowpipe (No. 14) and locked in the clockwise di-
rection (Fig. 6c).
Warning! Use only original manufacturer's replace-
ment parts, accessories and attachments. Failure to
do so can cause poor performance, possible injury and
may void your warranty. Never use the machine wit-
hout the guard assembled!
Operation
Before starting
Each time before use, check the following:
• That there are no leaks in the fuel system.
• That the equipment is in perfect condition and that the
safety devices and cutting devices are complete.
• That all screws are securely fastened.
• That all moving parts move smoothly.
Place the carrying strap
Pull the belt down, the straps are tightened
Loosen the straps
Lift the clamping slide
Adjust the carrying strap so that the back plate rests firm-
ly and securely against t
Fuel and oil
Recommended fuels
Use only a mixture of unleaded petrol and special 2-stro-
ke engine oil. Mix the fuel mixture as indicated in the fuel
mixing table.
Important: Do not use a fuel mixture which has been
stored for longer than 90 days.
Important: Never use 2-stroke oil with a recommended
mixing ratio of 100:1. The manufacturer's warranty
will be voided in case of engine damage due to inade-
quate lubrication.
Important: Only use containers designed and approved
for the purpose to transport and store fuel.
Pour the correct quantities of petrol and 2-stroke oil into
the mixing bottle (see scale printed on the bottle). Then
shake the bottle well.
Never use oil for 4-cycle engine or use water cooled
2-cycle engine. It can cause spark plug fouling exhaust
part blocking or piston ring sticking.
Mixed fuels, which have been left unused for a period of
one month or more, may clog the carburetor or result in
the engine foiling to operate property. Put remained fuel
into an airtight container and keep it in the dark and cool
room.
