English / Instruction
Sensor supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 x +24V DC 0.25A
Modbus communication . . . . . . . . . . . . . . . . . . . . . . . . . . RS-485, 38.4 kBaud, 24 VDC
Modbus address, OJ Zone Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . Self-configuring
Digital inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 x built-in pull-up
Supply voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 x +24V DC 0.1A
Digital outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 x potential free 230V AC 5A
Sensor inputs
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 x PT1000
Voltage input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 x 0-10 VDC
Measuring range, humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0-100 % RH
Measuring range, temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40 - 100 °C
Measurement range CO
Enclosure rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IP20
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (see fig. 2)
Weight
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .270 g
SERVICE AND MAINTENANCE
OJ GreenZone™ Module M contains no components that require service or mainte-
nance.
Please contact your supplier if faults arise.
DISPOSAL AND ENVIRONMENTAL PROTECTION
Help protect the environment by disposing of the packaging and redundant products in
an environmentally responsible manner.
Product disposal
Products marked with this symbol must not be disposed of together with
household refuse but must be delivered to a waste collection centre in accord-
ance with applicable local regulations.
OJ ELECTRONICS A/S
Stenager 13B · DK-6400 Sønderborg
Tel. +45 73 12 13 14 · Fax +45 73 12 13 13
oj@ojelectronics.com · www.ojelectronics.com
CE MARKING
2004/108/EC
15 December 2004 on the approximation of the laws of the Member States relating to
electromagnetic compatibility and repealing Directive 89/336/EEC.
12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 - 2000 ppm
2
EMC DIRECTIVE / The European parliament and of the council of
© 2017 OJ Electronics A/S
OJ GreenZone™ Module M
