4. GB- Product information

Symbols:
The following symbols have been used in the manual to draw attention to hazards or risk of damage to the
product.
Prohibition symbol:
Danger symbol:
!
!
• Use the device correctly following the manufacturer's instructions. If in doubt, contact the dealer.
• Prior to servicing the device: Disconnect the power and ensure it cannot accidentally be recon-
nected.
• Installation work should be carried out by qualified personnel in accordance with national regula-
tions.
• Follow the manufacturer's instructions for the device and general safety directions.
• This device must be earthed.
Disposal:

4.1 Contents of the package

Contains:
1 EW41 control panel
1 Power unit for installation on chimney
1 Temperature sensor
1 Bag containing brackets for the temperature sensor, rawlplugs, screws, etc.
4 AA (LR6) batteries
Installation and operation guide
Quick guide
The serial number can be found underneath the cover
on the back of the control panel

4.2 Accessories

Optional accessories (order separately)
Item no.
EW41REPEATER
0502232
1100703
0502301
Failure to observe instructions marked with a prohibition symbol may result in serious or
fatal injury
Failure to observe instructions marked with a danger symbol may result in personal injury
and/or damage to the unit.
TO MINIMISE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, PLEASE OBSERVE THE
FOLLOWING:
No special precautions. The product should be disposed of in accordance with national regulations
governing disposal of electronic waste.
Item
Signal amplifier If the power unit and control panel have to be placed at a distance
which exceeds the signal range, the signal can be boosted using a
signal amplifier. This may be purchased as optional equipment.
Power adapter If you wish to connect the control panel to mains power, use a
230 V power adapter. Batteries will then no longer be required.
Bracket for mounting on a If the power unit has to be mounted on a steel chimney, an
steel chimney installation kit is available for this purpose.
Additional control panel If you wish to be able to operate the chimney fan from more than one
control panel, several may be connected to the system.
EW41EUxx
Batch no.: xxxx
Version: x.xx
EW41EUxx
Batch no.: xxxx
Version: x.xx
