2. Layout (Fig. 1)
1. Air outlet opening
2. Upper half of housing
3. Carry handle
4. Mount for extension cable
5. Fan cover
6. Pressure indicator
7. Tank indicator
8. Tank cover
9. Power cable
10. Fuel tank
11. ON/OFF switch
12. Thermostat adjustor knob
13. LED
14. Lower half of housing

3. Intended use

The transportable low-sulphur heating-oil or diesel
driven hot air generator is ideal for heating and drying
well ventilated rooms in industry, agriculture,
construction and recreation (camping)
The appliance is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user/operator and not the manufacturer
will be liable for any damage or injuries caused as a
result thereof.
Please note that our appliance has not been
designed for use in commercial, trade or industrial
applications. Consequently, our warranty will be
voided if the appliance is used in commercial, trade or
industrial applications or for other equivalent
activities.

4. Mode of operation

The hot air generator is equipped with a compressor,
for suction of fuel out of the tank by creating a
vacuum. The suctioned fuel is directed to a blowpipe
nozzle. At the nozzle, a mixture of air and fuel is
created. The air and fuel mixture is ignited electrically
in the combustion chamber. The fan blows air into the
combustion chamber, which, after being heated, gets
blown out at the front. The thermostat knob can be
adjusted to create the right temperature. After this
temperature has been reached the appliance is
automatically switched off, and if the temperature
should drop again, it is automatically switched back
on.
27.03.2009 14:34 Uhr Seite 15
A photo cell permanently monitors the combustion
process and turns the appliance on or off if there are
irregularities. If overheating occurs, the appliance will
also switch off.
If this is the case, please contact customer service.
The electrical components are protected by a
miniature fuse (fusible insert). If there is a fault in the
miniature fuse, please contact customer service.

5. Technical data

Power supply:
Heat output (Hi):
Heat settings:
Fuel:
Pump pressure:
Fuel consumption:
Tank capacity:
Power rating:
Air flow rate:
Maximum air temperature:
Appliance dimensions:
Appliance weight:

6. Before starting the appliance

Before you connect the appliance to the power
supply make sure that the data on the rating plate
are identical to the mains data.
Always place the portable device on firm,
horizontal ground.
The device must always be in an upright position.
Take care that the minimum separating distance
between the appliance and other objects is 2.5m
at the front, 1.25m at the rear and the side.
The appliance must only be used in well-
ventilated rooms or outdoors. The required size of
the air intake opening in the room is 0.02m
kW of heat output. For a heat output of 20kW the
openings would need to be 0.4m
addition, be sure to open windows and doors
outwards.
6.1 Assembly (Fig. 2).
Screw the carrying handle (Fig. 2/Item 3) onto the
upper half of the housing (Fig. 2/Item 2)
Screw the mount for the extension cable (Fig.
1/Item 4) onto the side.
GB
230 V ~ 50Hz / 1.5A
20 kW
1
Low-sulphur heating-oil or diesel
0.28 bar
2.0 l/h
19 l
170 W
400 m
3
393 °C
76 x 30.5 x 38 cm
13 kg
per
2
2 in total size. In
