When rigging, derigging or servicing the device staying in the area below the installation place, on bridges,
under high working places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert before taking into operation for the first time and after changes before taking into operation another
time.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert after every four year in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are approved by a
skilled person once a year.
Procedure:
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including (but not limited to)
calculating working load limits, installation material being used, and periodic safety inspection of all
installation material and the device. If you lack these qualifications, do not attempt the installation yourself,
but instead use a professional structural rigger. Improper installation can result in bodily injury and or
damage to property.
The device has to be installed out of the reach of people.
Before rigging make sure that the installation area can hold a minimum point load of 10 times the device's
weight.
The device must always be installed via all fixation holes. Do only use appropriate screws and make sure
that the screws are properly connected with the ground.
The durability of the installation depends very much on the material used at the installation area (building
material) such as wood, concrete, gas concrete, brick etc. This is why the fixing material must be chosen to
suit the wall material. Always ask a specialist for the correct plug/screw combination indicating the maximum
load and the building material.
Procedure:
Step 1: On the baseplate, there are thr holes for the installation.
Step 2: Hold the baseplate onto the location where the device is to be installed.
Step 3: Mark the boreholes with a pen or a suitable tool.
Step 4: Drill the holes.
Step 5: Hold the baseplate in the desired position and tighten it.
The electric connection must only be carried out by a qualified electrician!
Install the power supply for the CL-50 in the Lamp-output terminals. In order to connect the CL-50 to the
mains, you have to install an appropriate transformer with a 12 V/60 VA output between the Lamp-output
and the CL-50.
Install the data cables and power cables between ICL-6 and CL-50 and between more CL-50s. For the
connection between several CL-50s, you can use any data socket.
Please note: You can connect up to four CL-50s to every output socket of the ICL-6 (all CL-50s work
synchronically). The data connection must be carried out via a network cable with RJ45 plugs and an
occupation of 1 to 1. The maximum length of the individual data cables is 10 meters. The total length must
never exceed 40 meters.

DANGER TO LIFE!
