CHANNEL 3: strobe
CHANNEL 4: pan
CHANNEL 5: tilt
CHANNEL 6: dimming 0-100%
It is possible to link multiple units for synchronous operation by means of the enclosed DMX cable.

6. Cleaning and Maintenance

1. All screws should be tightened and free of corrosion.
2. The housing, the lenses, the mounting supports and the installation location should not be deformed, modified or
tampered with e.g. do not drill extra holes in mounting supports, do not change the location of the connections, ...
3. Mechanically moving parts must not show any signs of wear and tear.
4. The electric power supply cables must not show any damage. Have a qualified technician maintain the device.
5. Disconnect the device from the mains prior to maintenance activities.
6. Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
7. There are no user-serviceable parts, apart from the lamp and the fuse (see "Installation").
8. Contact your dealer for spare parts if necessary.

7. Technical Specifications

Power Supply
Power Consumption
Fuse
Dimensions
Total Weight
Lamp
Max. Ambient Temperature
Lighting resistance
Insulation resistance
Signal
Use this device with original accessories only. Velleman nv cannot be held responsible in the event of
damage or injury resulted from (incorrect) use of this device. The information in this manual is subject to
change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All worldwide rights reserved.
No part of this manual or may be copied, reproduced, translated or reduced to any electronic medium or otherwise
without the prior written consent of the copyright holder.
1. Inleiding en kenmerken
Aan alle ingezetenen van de Europese Unie
Belangrijke milieu-informatie betreffende dit product
Dit symbool op het toestel of de verpakking geeft aan dat, als het na zijn levenscyclus wordt weggeworpen,
dit toestel schade kan toebrengen aan het milieu. Gooi dit toestel (en eventuele batterijen) niet bij het gewone
huishoudelijke afval; het moet bij een gespecialiseerd bedrijf terechtkomen voor recyclage. U moet dit toestel
naar uw verdeler of naar een lokaal recyclagepunt brengen. Respecteer de plaatselijke milieuwetgeving.
Hebt u vragen, contacteer dan de plaatselijke autoriteiten inzake verwijdering.
VDP250SC6
max. 230VAC / 50Hz
max. 250W
F 5A, 250VAC (5 x 20mm) (order code FF5N)
500 x 270 x 160mm
9kg
250W / 24V ELC GX5.3 [order code LAMP250/24ELC (Philips)]
45°C
1.5kV
>2Mohm
international standard DMX512
VDP250SC6 – 6-KANAALS SCANNER
