control board logic system may be compromised, resulting into a
possible operation block.
T
ECHNICAL DATA
- Moisture
- Power supply voltage
- Frequency
- Max. power consumption of the card
- Transient power mains drops
- Max. capacity of the warning light - gate open 3 W
- Max. load at blinker output
- Available current for photocells and accessories 0,4 A ±15% 24Vac
- Available current for the radio connector
- All the inputs must be used as clear contacts because the power
supply is generated inside (safe power) the control panel, and it has
been laid down in such a way to guarantee a double or strengthened
insulation in relation to the parts with dangerous power.
- Eventual external circuits connected to the outputs of the control
board or of the expander card must be carried out making sure that a
double or strengthened insulation is used in relation to parts with
dangerous power.
- All inputs are run by a programmed integrated circuit which does a self
check every time it starts operating.
< 95%
without condensation
230V~ ±10%
50/60 H
60 mA
100mS
(corresponding to 1
3W lamp or to 5
LEDS with 2,2 k
resistance In series)
40W with resistive load
200mA 12Vdc
