7 - At the end of the control, and of the trimmers' adjustements,
position DIP1 on mode OFF. The LED DL5 turns off, signalling you
exit from the control.
NB: The photocells are not active during this control.
- D -
TIME PROGRAMMING
NB: DIP7 SHALL BE ON MODE OFF!!
The programming can be carried out regardless of the gate position.
1 - Put DIP 2 in the ON mode => the LED DL5 emits short blinkings.
2 - Push the button PROG. => the gate closes and opens automatically
2 seconds after It closed. When the opening cycle Is terminated, It
stops. Wait as long as you want the gate to remain open (excluded
by DIP3 OFF)
3 - Push the button PROG. to command the gate closing (also the
pause time count before the automatic closing stops - max. 5
minutes).
4 - The gate stops as the closing cam is reached.
5 - WHEN THE TIME PROGRAMMING IS COMPLETED, POSITION
DIP 2 ON MODE OFF.
NOTE: The deceleration speed is set automatically by the control panel
during the time programming. The deceleration starts
automatically about 15÷20 cm before the gate reaches the limit
switch in opening and closing.
O
PERATION OF THE OPERATING ACCESSORIES
OPENING BUTTON (with timer function)
When the gate is standstill, the button operates the opening mode. If
you push this button when the gate is on closure, It opens again.
TIMER FUNCTION
This function is useful In the rush hours, when vehicle traffic is slow
(e.g. entry/exit of workers, emergencies In residential or parking areas
and, temporary, for removals).
APPLICATIONS
By connecting a switch and/or a daily/weekly timer (in place or in
parallel with the opening button N.O. "COM-OPEN"), it is possible to
open the automation or to keep It open, as long as the switch is on or
the timer is activated.
When the automation is open, all operating functions are inhibited.
If the automatic closing Is started, by releasing the switch or at the time
set before, the automation immediately closes; if not, you need to
operate a command.
CLOSING BUTTON (COM-CLOSE)
When the gate Is standstill, It operates the closing.
JOGGING OPERATION BUTTON (COM-K BUTTON)
If DIP5 is OFF => It cyclically commands open-stop-close-stop-open-
etc.
If DIP5 is ON => It opens the gate when this Is closed. If It Is operated
while the gate Is opening, It has no effect. If It Is
operated when the gate is open, it closes the gate
and, If It Is operated while the gate Is closing, It
opens the gate again.
RADIO TRANSMITTER
If DIP4 is OFF => It cyclically commands open-stop-close-stop-open-
etc.
If DIP4 is ON => It opens the gate when this is closed. If It Is operated
while the gate Is opening, It has no effect. If It Is
operated when the gate Is open, It closes. If It Is
operated while the gate Is closing, It opens the gate
again.
AUTOMATIC CLOSING FOR COMPLETE OR PEDESTRIAN
OPENING
The pausing time before the automatic closing for both, complete or
pedestrian opening is set during the time programming. In both cases
the maximum pausing time available is 5 minutes . Pause time can be
started or stopped by DIP3 (ON started).
OPERATION AFTER BLACK-OUT
When mains electrical power is restored press the opening button (K,
OPEN, radio).
The gate will open. Let the gate close itself with automatic closure or
wait that the flasher stops blink first to command the closing movement.
This operation is valid to obtain the leaves position readjustment.
During this phase all safety devices are active.
S
AFETY ACCESSORIES OPERATION
PHOTOCELL 1 (COM-PHOT 1))
If DIP 6 is OFF => The gate does not open if there Is an obstacle
within the photocells range of action. During
operation, photocells work both when the gate
opens (by starting the opening movement again
after half a second time), and when It closes (by
starting the reverse movement after one second
time).
If DIP 6 is ON => If there Is an obstacle within the photocells range of
action when the gate is closed and its opening Is
commanded, the gate opens (during Its opening,
photocells do not work).
Photocells work only while the gate Is closing (by starting Its reverse
motion after one second, even if they are still engaged).
STOP BUTTON
The STOP button stops the gate during any operation.
If you push it when the gate is totally open (or partly open, by using the
pedestrian command), this button temporary excludes the automatic
closing (if selected by DIP3 and DIP9). It Is than necessary to operate
another command to make the gate close again.
The automatic closing function Is enabled again with the following
operating cycle (if selected by DIP3 and DIP9).
BLINKER
N.B.: This electric board can supply power ONLY TO BLINKERS
WITH (ACG7059) BLINKING CIRCUIT, with max. 40W lamps.
PRE-BLINKING FUNCTION:
With DIP8 on OFF => the motor, the blinker and the buzzer start at the
same time.
With DIP 8 on ON => the blinker and the buzzer start 3 seconds
before the motor.
BUZZER (Optional)
Buzzer - Wiring acoustic warning (12Vdc max 200 mA)
The buzzer emits an intermittent sound signal during opening and
closing cycles. When safety devices are operated (alarm), the
intermittence frequency of this sound signal Increases.
WARNING LIGHT - GATE OPEN (COM-SIGNAL):
Its function Is to signal when the gate Is open, partly open or not totally
closed anyway. It turns off only when the gate Is totally closed.
This warning signal is not enabled during the programming procedures.
N.B.: If you overuse the push button panels or the lamps, the
