● Only allow trained persons to use the tool. Apprentices may only use the
tool when they are over 16, when this is necessary for their training and
when they are supervised by a trained operative.

1. Technical Data

Use for the intended purpose
CAUTION CAUTION
ROLLER'S Convex, ROLLER'S Polo, ROLLER'S Hydro-Polo are intended for the purpose of cold pressure bending of pipes up to 90°.
All other uses are not for the intended purpose and are therefore prohibited.
1.1. Scope of Supply
ROLLER'S Convex:
ROLLER'S Polo up to Ø 26 mm:
ROLLER'S Polo up to Ø 32 mm:
ROLLER'S Hydro-Polo up to Ø 26 mm: Oil-hydraulic hand pipe bender, bending formers according to ordered set, back former supports H-S Ø 10 – 26 mm,
ROLLER'S Hydro-Polo Ø 32 mm:
1.2. Article numbers
Drive unit
Bending formers
Roller (pack of 2)
Back former Ø 75 mm (pack of 2)
Back former support S Ø 10–26 mm
Back former support H-S Ø 10–26 mm
Back former support Ø 32 mm
Tripod stand
Device for reverse bend
Transport box
Steel case
Case
Angle meter
Machine cleaner
1.3. Applications
No cracks or wrinkles shall occur during professional cold bending. Pipe qualities and dimensions which do not guarantee this are not suited to be bent with
ROLLER'S Convex, ROLLER'S Polo and ROLLER'S Hydro-Polo.
Steel pipes EN 10255 5 5
Soft copper pipes, also thin-walled
Soft coated copper pipes
Stainless, nickel steel pipes of the press fi tting systems Stainless, nickel steel pipes of the press fi tting systems Stainless, nickel steel pipes of the press fi tting systems
Soft coated carbon steel pipes of the pressfi tting systems
Soft precision steel pipes
Composite tubes
Largest bending angle
Hard copper pipes must be softened by annealing!
1.4. Dimensions L × W × H
Bender drive with
Roller holder/back former support
Tripod stand
1.5. Weights
Bender drive with roller holder/back former support
Tripod stand
Bending formers from – to
2. Start-up
CAUTION CAUTION
Transport weights above 35 kg must be carried by at least 2 persons. When
transporting and installing the tool, please note that the tool has a high centre
of gravity with and without the base frame, i.e. it is top heavy.
Oil-hydraulic pipe bender, 2 roller holders, 2 rollers, bending formers according to ordered set, operating instructions,
transport box.
One-hand pipe bender, bending formers according to ordered set, back former supports S Ø 10 – 26 mm, steel case,
operating instructions.
One-hand pipe bender, bending formers according to ordered set, back former supports S Ø 10 – 26 mm, back former
supports Ø 32 mm, case, operating instructions.
case, operating instructions,
Oil-hydraulic hand pipe bender, bending formers according to ordered set, back former supports H-S Ø 10 – 26 mm,
back former supports Ø 32 mm, case, operating instructions.
ROLLER'S Convex
see Fig. 3
Ø 32 – 75 mm
670 × 680 × 620 mm
(26.4" × 26.8" × 24.4")
650 × 630 × 525 mm (25.6" × 24.8" × 20.7")
35.0 kg (77.2 lb)
4.6 kg (10.1 lb)
0.4 – 4.9 kg (0.9 – 10.8 lb)
Explanation of symbols
CAUTION CAUTION
Danger with a low degree of risk which could result in minor
injury (reversible) if not heeded.
NOTICE
Material damage, no safety note! No danger of injury.
Read the operating manual before starting
CE conformity mark
590000
590110
590111
590150
590160
590153
140119
Ø ⅜ – 2" Ø ⅜ – 2"
Ø 10 – 22 mm, Ø ⅜ – ⅞", s ≤ 1 mm
Ø 10 – 18 mm, Ø ⅜ – ⅝", s ≤ 1 mm
Ø 12 – 18 mm, s ≤ 1.2 mm
Ø 10 – 18 mm, s ≤ 1 mm
90°
318 × 252 × 140 mm
(12.5" × 9.9" × 5.5")
0.06 – 0.3 kg (0.13 – 0.7 lb)
2.1. ROLLER'S Convex Fig. 1 – 3
Place the bender drive (4) on a fi rm, level base. Make sure that there is enough
room for the fully assembled pipe bender and the pipe to be bent. Insert the
lower roller holder (1) into the lower groove of the bender drive (4) so that the
feet (16) are facing down and the bolt (5) can be inserted. Secure the bolt (5)
with the spring loaded pin (6). Insert the upper roller holder (2) into the upper
groove of the bender drive (4) so that the angle marking (14) is legible, fi x with
the bolt (5), secure the bolt with the spring-loaded pin (6). Insert the rollers (7)
ROLLER'S Polo
153100
see Fig. 6
153125
153115
153140
153265
153270
590153
140119
Ø 10 – 22 mm, Ø ⅜ – ⅞", s ≤ 1 mm
Ø 10 – 18 mm, Ø ⅜ – ⅝", s ≤ 1 mm
Ø 12 – 22 mm, s ≤ 1.2 mm Ø 12 – 22 mm, s ≤ 1.2 mm
Ø 12 – 18 mm, s ≤ 1.2 mm
Ø 10 – 22 mm, s ≤ 1.5 mm
Ø 14 – 32 mm
90°
1.4 kg (3.1 lb)
0.06 – 0.3 kg (0.13 – 0.7 lb)
eng
ROLLER'S Hydro-Polo
153500
see Fig. 8
153501
153115
153570
590153
140119
Ø 14 – 32 mm
90°
428 × 252 × 170 mm
(16.9" × 9.9" × 6.7")
3,. kg (6.8 lb)
9
