Electromagnetic compatibility

This PF Controller has been verified for compliance with EU
(European Union) directives for EMC (electromagnetic compatibility)
for operation at 50 Hz and bears the CE marking to this effect.
When an apparatus is used in a system, EU directives may require
that the system be verified for EMC compliance.
The following guidelines are helpful in improving the EMC
performance of a system:
1. Metallic enclosures generally improve EMC performance.
2. Run cables away from apertures in the enclosure.
3. Run cables close to grounded metallic structures.
4. Use multiple ground straps for doors or other panels parts as
required.
5. Avoid common ground impedances.
FIGURES (refer to doc n° 2GCS201086A0050 1/2)
# 1. Front view
1.1. Mounting brackets
1.2. LCD display
1.3. Keypad
# 2. Rear view
2.1. Mounting brackets
2.2. L2 & L3, voltage
connection inputs
2.3. k & I, current connection
inputs
2.4. Steps outputs
# 3. LCD display
3.1. Activated outputs
3.2. Overtemperature indication
3.3. Disconnection indication
3.4. User settable parameters
3.5. Modes
3.6. Demand for switching on or
off capacitor steps
3.7. Inductive PF
3.8. Capacitive PF
3.9. Alarm indication
3.10. Measurement unit
3.11. Refer to § Feature
# 4. Keypad
4.1. Mode button
4.2. - button
4.3. + button
# 5. Mounting
5.1. Slide the controller into the
capacitor bank cubicle.
5.2. Insert the mounting brackets
in the corresponding fixation
holes of the controller. Pull the
mounting brackets backwards.
5.3. Turn the screw into the
mounting brackets and tighten
until the controller is fixed.
