• MAIN: This shows the current software version loaded into the RC-1590.
The software can be updated if the RC-1590 is properly connected to
the Internet.
• Press ENTER to check if a new software version is available.
• If a new software version is available press the + button on the front
panel or the right button on the remote control to select YES then press
ENTER button to begin the software update process.
• The new software will be downloaded from the Internet. The RC-1590
will power cycle when the software update is complete.
NOTE: Do NOT power off the RC-1590 during the software update
process.
NOTE: It is recommended to Reset Factory Defaults after the software
update is complete.
• PC-USB: This shows current loaded software version for PC-USB processor.
• FACTORY DEFAULT: This sets the unit back to the original state as when
it left the factory. Press the + button on the front panel or the Right button
on the remote control to select <YES> then press the ENTER button on the
front panel or on the remote control.
NOTE: All previously configured options will be erased and reset to
the factory default settings.

Troubleshooting

Most difficulties in audio systems are the result of incorrect connections,
or improper control settings. If you encounter problems, isolate the area
of the difficulty, check the control settings, determine the cause of the fault
and make the necessary changes. If you are unable to get sound from the
RC-1590, refer to the suggestions for the following conditions:

Power Indicator Is Not Illuminated

The Power Indicator ring around the power button and the basic items in the
Display window should be illuminated whenever the RC-1590 is plugged
into the wall power outlet and the POWER switch is pushed in. If it does not
light, test the power outlet with another electrical device, such as a lamp.
Be sure the power outlet being used is not controlled by a switch that has
been turned off.

Fuse Replacement

If another electrical device works when plugged into the power outlet, but
the Power Indicator still will not light when the RC-1590 is plugged into
the wall outlet, it indicates that the internal power fuse may have blown.
If you believe this has happened, contact your authorized Rotel dealer to
get the fuse replaced.

No Sound

Check the signal source to see if it is functioning properly. Make sure the
cables from the signal source to the RC-1590 inputs are connected properly.
Check all the wiring between the RC-1590 and the power amplifier, and
the speakers.

Playable Audio Format

USB Apple (iPhone, iPod, iPad)
Format
Any supported file loaded to Apple device. Phone
Any supported file
may resample depending on stored format. May
loaded to Apple
exclude Apps designed to play formats not originally
device.
supported by the sending device.
APTX Bluetooth
Format
Any format supported May exclude Apps designed to play formats not originally
by the sending device. supported by the sending device.
PC-USB
Format
Format determined Any supported format by the PC software
by the Media Player/ PCM Audio: 44.1k, 48k, 88.2k, 96k, 176.4k, 192k,
Server software that 384k (16 bit, 24 bit and 32 bit )
you use. DSD64 and DSD128
Coax/Optical
Format
44.1k, 48k, 88.2k, 96k, 176.4k, 192k
SPDIF LPCM
16 bit, 24 bit
RC‑1590 Stereo Control Amplifier
