3. Web Server Quick Guide
Item
Overall plant sta-
tus
3
Current production kW
Yield today
Total revenue
Total CO
Performance ratio
Total yield
Power limit adjust-
ment
Note:
To calculate performance ratio PR, an irradiation sensor is required, see [Setup → Calibra-
tion].

3.5. Additional Information

Refer to the Web Server User Manual to learn more about:
•
•
•
•
•
•
•
22
Unit View
Plant Inverter
and
Group
- x
x
x x
kWh x x
Euro x x
saving kg x x
2
% x x
kWh x x
% x
Inverter start-up and check of settings
Messaging
Graphs
Remote access
Web portal upload
Logging capacity and changing the logging interval
Settings backup and restore
Description
Red: Plant PR < 50 %, or:
Any inverter in the network
fail safe mode, or
- in
- missing from the scan list, no contact with the master
Yellow: Any inverter in the network
- with PR < 70 %, or
Connecting or Off grid mode
- in
Green: Plant PR ≥ 70 %, and
- all inverters with PR ≥ 70 %, and
On grid mode
- all inverters in
Red: Inverter PR < 50 %, or inverter has an error
Yellow: Inverter PR between 51 % and 70 %, or inver-
ter in Connecting mode
Green: No errors, and
- inverter PR ≥ 70 %, and
- inverter in On grid mode
Real time energy production level
Cumulative yield for the day
Cumulative revenue earned since initial startup
Cumulative CO saved since initial startup
2
Real time performance ratio
Cumulative yield since initial startup
Maximum power limit as % of nominal inverter AC output
rating
