2.1.5. Setup

Menu Structure - Setup
Display Functions
[-] Relay
Function: Alarm
Stop Alarm
Test Alarm
Alarm state: Disabled
Alarm time-out: 60 s
Function: Self-consumption
Power level
Duration
Trigger time
[-] Setup details
Language: English
[-] Inverter details
Inverter name:
Danfoss
Group name:
Group name
[-] Master mode
Master mode: Enabled
[-] Network
Plant name:
Plant name
[-] Set date and time
Date: dd.mm.yyyy (30.12.2002)
Time: hh.mm.ss (13.45.27)
[-] Calibration
[-] PV array
PV input 1: 6000 W
PV 1 area: 123 m
PV input 2: 6000 W
PV 2 area: 123 m
PV input 3: 6000 W
PV 3 area: 123 m
[-] Irradiation sensor
Scale (mV/1000 W/m
Temp. coeff: 0.06 %/
[-] Temp. sensor offset
PV module temp: 2
Ambient Temp: 2
[-] S0 sensor input
Scale (pulses/kWh): 1000
[-] Environment
CO
0.5 kg/kWh
Remuneration per kWh:
44.42 ct/kWh
Yield start count: 1000 kWh
[-] Communication setup
[-] RS485 setup
Network: 15
Subnet:15
Address: 255
[-] IP Setup
IP config: Automatic
IP address:
192.168.1.191
Subnet mask:
255.255.255.0
Default gateway:
192.168.1.1
DNS server:
123.123.123.123
Table 2.7: Setup
Description
Only applicable if external alarm is connected
Default setting of Function
Stop alarm
Includes testing red LED on front
Alarm time limit. If 0, the alarm will be active until fixed
Minimum level to activate self-consumption
Duration of power level to activate self-consumption
Hour of day to activate self-consumption
The language in the display; changing the display language does
not affect country setting
The inverter's name. Max. 15 characters and not only numbers.
The name of the group the inverter is part of
*
Max. 15 characters
*
*
* Only visible if Master mode is enabled.
[-] Initiate network scan
[-] Scan progress: 0%
[-] Inverters found: 0
* The name of the plant.
* Max. 15 characters
Set the current date
Set the current time
Only applicable if sensors are connected
2
2
Not visible if inverter only has 2 PV inputs
2 Not visible if inverter only has 2 PV inputs
Sensor calibration
2 ): 75
o Sensor calibration
C
Sensor calibration (offset)
o C
o Sensor calibration (offset)
C
Sensor calibration. See note
Value to be used for total CO
emission factor: *
2
*
* Value to be used for total revenue calculation
A value used as an offset from the current production value when
*
calculating the yield.
Only applicable if communication accessories are connected
L00410310-07_2q
2. Display
saved calculation
2
2
