2. Display
*) For TLX Pro only.
Menu Structure - Setup - Continued
Display Functions
2
[-] Autotest
[-] Logging
[-] Web Server
[-] Service
[-] Reactive power
[-] Security
Table 2.8: Setup - Continued
*) For TLX Pro only.
12
GPRS connection setup
SIM PIN code: 0000
Access point name:
name
User name:
user
Password:
password
Roaming: Disabled
[-] Data warehouse service
Upload channel: LAN
Upload time (h:m): 14:55
Start log upload
D.W FTP server address:
www.meteocontrol.de
D.W server port: 65535
FTP mode: Active
D.W. server user name:
User
D.W server password
Password
Status: Off
Ugrid: 234 V
Utest: 234 V
Fgrid: 50.03 Hz
Ftest: 50.03 Hz
Disconnection time: 53 ms
Interval: 10 min *
Logging capacity:
10 Days
Reset password
*
*
Store settings
*
Restore settings
Replicate settings *
[-] Setpoint type
Off
Const Q
Const PF
*
Q(U)
PF(P) *
Value
State
Password: 0000
Security level: 0
Log out
[-] Service logon
User name:
user name
Password:
password
Description
4-8 characters
Max. 24 characters
Max. 24 characters
Max. 24 characters
Requires data from at least 10 min. of energy production
Default serial number of the inverter
User name for Data warehouse account, max. 20 chars.
Password for Data warehouse account, max 20 chars.
Initiate autotest, only applicable with country setting; Italy
Only visible during voltage tests
Only visible during voltage tests
Only visible during frequency tests
Only visible during frequency tests
Not visible in Off and Completed OK states
The interval between each logging
Resets the password of the Web Server to its default value
Store inverter settings and data in the display of the inverter.
Restore all inverter settings and data stored in the display of the in-
verter.
Replicate all inverter settings to all other known inverters in the net-
work. Only visible if master mode is enabled.
No setpoint
Constant reactive power Q
Constant power factor PF
Reactive power defined as a function of grid voltage – set up data sets
via web server interface
Power factor defined as a function of plant output power – set up data
sets via web server interface
Value is dependent on setting of 'setpoint type':
- Off: no value
- Const Q : enter Q (0 - 100 %)
- Const PF: enter PF (0.00 – 1.00)
Overexcited or underexcited
Level of access to inverter parameters and settings
Current security level
Log out to security level 0
Only to be used by authorised service personnel
