3. Web Server Quick Guide

3. Web Server Quick Guide

3.1. Introduction

3
These instructions describe the TLX Pro Web Server, which facilitates remote access to the in-
verter.
The Web Server is available in TLX Pro and TLX Pro+ inverters only.
Refer to the download area at www.danfoss.com/solar for the newest instructions.

3.2. Supported Characters

For all language versions, the Web Server software supports characters compatible with Uni-
code.
For plant, group and inverter name, only the following characters are supported:
Letters
Capital letters
Numbers
Special characters - _.
Note! No spaces are allowed in inverter name.

3.3. Access and Initial Setup

3.3.1. Access via PC Ethernet Interface
Setup Sequence:
1.
2.
3.
4.
5.
14
abcdefghijklmnopqrstuvwxyz
ABCDEFGHIJKLMNOPQRSTUVWXYZ
0123456789
Change the Web Server logon and password of the master inverter immediately
for optimal security when connecting to the internet. To change the password go
to [Setup → Web Server → Admin].
Select which inverter will be set up as master.
Open the cover of this inverter. Refer to the TripleLynx Installation Manual for instruc-
tions.
Connect the inverter RJ45 interface to the PC Ethernet interface using a patch cable
(network cable cat5e, crossed or straight through).
On the PC, wait until Windows reports limited connectivity (if no DHCP is present).
Open the internet browser and ensure pop-ups are enabled.
Type http://invertername in the address field:
• Find the serial number on the product label, located on the side of the hous-
ing.
• 'Invertername' is the final 10 digits of the serial number (1).
L00410310-07_2q
