Renew gear unit.
Gear unit noisy. The table top makes
1/3 of a revolution and then stops
Gear unit seizing.
Renew gear unit.
Table top fails to clamp wheels
Table top does not clamp rim.
Renew table top cylinder.
Clamp grippers are worn.
Renew clamp grippers
Table top mounts or demounts tyres
with difficulty
Insufficient belt tension.
Adjust belt tension (fig.23) or renew
it.
Vertical slide lifts too little or too far
from rim
Clamping plate not adjusted.
Adjust plate
Vertical slide ascends under strain
Defective clamping plate.
Renew plate.
Clamping plate not adjusted.
Adjust plate.
When the tower tilts back, the arm
and vertical slide slip to their limit
stops
Defective clamping plate.
Renew plate.
Clamping plate not adjusted.
Adjust plate.
Vertical and horizontal limit stops do
not operate
No air passage through cock.
Renew cock.
Tower does not tilt
Faulty tower tilt cylinder.
Renew tower tilt cylinder.
No air supply to cylinder.
Renew cock.
Air escapes from cock.
Renew cock or tower tilt cylinder.
Arm and vertical slide locking cock
e - Operator manual
nglIsh
leaks air
Valve seal damaged.
Renew cock knob.
Air leaks from air clamping cylinders
Faulty piston or seals.
Change pistons and seals.
The tower tilts violently or slowly
(fig. 24)
Incorrect release valve setting.
Adjust.
Hares: increase speed.
Tortoise: decrease speed.
Tyre pressure gauge needle fails to
return to 0
Pressure gauge faulty or damaged.
Renew pressure gauge.
WARNING
The "Spare parts" handbook does not
authorise the user to carry out work on
the machine with the exception of those
operations explicitly described in the
user's manual, but enables the user to
provide the technical assistance service
with precise information, in order to
reduce delay.
