Ambient conditions for storage and
transport
Temperature range from -25∞ to +55∞
WARNING
Do not stack other goods on top of the
packing or damage may result.
Handling
To move the packed machine insert the
forks of a pallet truck in the channels in
the base of the pallet (fig.1).
Before moving the machine refer to the
chapter HOISTING AND MOVING
ATTENTION
Keep the packing material intact for pos-
sible future transport of the machine.

UNPACKING / ASSEMBLY

ATTENTION
Take the utmost care when unpacking,
assembling, and setting up the machine
as described in this heading.
Failure to observe these instructions can
lead to damage to the machine and injury
to the operator or other persons.
- Remove the upper part of the packing
and make sure that the machine has not
suffered damage in transit; identify the
points at which the machine is anchored
to the pallet.
- The machine comprises five main sec-
tions (fig.1):
1.tower
2.tower guard
3.box with pressure gauge
4.air tank
5.cabinet
- After removing the tower 1, it is advi-
sed to place it in a horizontal position
to prevent it from falling and getting
damaged.
- Take off the side cover.
- Insert the air hose G fig.2 into hole A
behind the tower tilt cylinder.
e - Operator manual
nglIsh
- Assemble the tower 1, insert pin B into
hole C and lock with screw and washer
D.
- Insert pin E into hole F and into U-bolt
F1 on the tower tilt cylinder and lock
with ring M.
- Connect hose G to the intermediate
connection linked to the tower-lifting
cock H.
- Fit the box with pressure gauge 3 on
to the tower 1 and lock with screw and
washer S.
- Fit the tower guard 2 and lock with
screws and washers L.
- Insert the tank 4 outlet into hose Q. Fix
the tank 4 to the machine with nuts and
washers R and tighten clamp O on hose
Q (FI version only).

HOISTING / MOVING

To remove the machine from the pallet,
sling it as shown in figure 3.
This lifting point must be used whenever
you need to change the position of the
machine. Do not attempt to move the
machine until it has been disconnected
from the electrical and air networks.
