Replacing Batteries

When replacing batteries:
1 . Tur n the camera and TR-90 off and
disconnect the TR-90.
2. Remove the batteries.
3. Insert new batteries
INSTRUCTION MANUAL
En
Parts of the TR-90 The Illuminator/Lock Button
P r e s s t h e i l l u m i n a t o r / l o c k b u t t o n
( ) briefly to activate the control panel
backlight. The backlight will remain lit for
about six seconds; pressing the selector
button ( ) while the backlight is on
extends the timer for another six seconds. To
lock all controls except the shutter-release
( ) and illuminator/lock buttons, press
the illuminator lock button until the lock
icon( ) is displayed in the control panel.
To release the lock, press the illuminator/
lock button until the lock icon is no longer
displayed.
7
