MODELS

ELECTRICAL CHARACTERISTICS

Current capacity of contacts
Switching voltage on the contact

AMBIENT CHARACTERISTICS

Operating temperature
(2)
Protection rating
CASE
Dimensions (LxHxD)
GENERAL
Maximum cable extension
EMC class
(1) Continuous operation with resistive load.
(2) With the plug correctly inserted into the socket. Excluding the area of the socket where the exit cable is fixed (IP 00).
®
QUICK RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT PRIOR NOTICE.
HRC100X-SUPPLEMENTARY - REV03A
HRC 1002 XXX
HRC 1002 L XXX HRC 1004 L XXX
(1)

TECHNICAL DATA

HRC1004 XXX HRC 1006 XXX
HRC 1006 L XXX
2,5A
30 Vdc Max
-15 ÷ +70 °C
IP 67
62.2 x 185 x 49.4 mm
4.2 m
EN 55022/B
GB
HRC 1008 XXX
HRC 1008 L XXX
11 11
