7 . T EC H N I CAL SPE C I F I CAT ION S

GENERAL INFORMATION

Remote control battery: Rechargeable 3.7[V] / ≥ 1,500[mAh] lithium polymer (LiPo) battery.
Module battery: Rechargeable 3.7[V] / ≥ 450[mAh] lithium polymer (LiPo) battery.
SP 6.0 and 8.0 AC power adapter: Only 5[V] / 3.5 [A] AC power adapters bearing reference number 64902X
can be used to recharge your device.
FIT 5.0 AC power adapter: Only 5[V] / 1.5 [A] AC power adapters bearing reference number 00108X can be
used to recharge your device.
Product and accessories expected service life: 5 years
Electrode shelf life: refer to electrodes bag

NEUROSTIMULATION

All the electrical specifications are supplied for an impedance from 500 to 1000 ohms per channel.
Outputs: four independent and individually adjustable channels, electrically insulated from one another.
Impulsion form: constant rectangular current with compensated impulses to eliminate any direct element of
continuous current to avoid any residual polarisation from the skin.
Maximum impulse intensity: 120 mA.
Impulse intensity increments: manual adjustment of stimulation intensity from 0 to 999 (energy) by minimum
increments of 0.25 mA.
Duration of impulses: from 50 to 400 μs.
Maximum quantity of electricity per impulse: 96 microcoulombs (2 x 48 μC, compensated).
Typical impulse rise time: 3 μs (20%-80% of maximum current).
Frequency of impulses: 1 to 150 Hz.
