Table extension
Attach the table extension (6) using the two struts (5) and the cross brace inside it. Use 6 of the M6 × 16 mm
bolts with nuts and washers. Finger-tighten the bolts. The table extension can also be attached to the side of
the table to widen it. In this case, the shorter struts should be used.
Dust extraction port
Attach the dust extraction port (7) to the lower blade guard
using 4 of the M6 × 16 mm bolts, M6 nuts and washers.
Wheels
1. Attach the wheels to the back legs using 4 of
the M6 × 16 mm bolts, M6 nuts and washers.
Finger-tighten the bolts.
2. Turn the table saw the right way up. Make sure
that all the legs are touching the ground.
Tighten all the nuts and bolts except for those in
the wheels.
3. Adjust the height of the wheels so that they just
touch the ground. Tighten their nuts and bolts.
