CORDLESS DRILL
Thank you for buying this Ferm product.
By doing so you now have an excellent product,
delivered by one of Europe's leading suppliers. All
products delivered to you by Ferm are
manufactured according to the highest standards
of performance and safety. As part of our
philosophy we also provide an excellent customer
service, backed by our comprehensive Warranty.
We hope you will enjoy using this product for many
years to come.
The numbers in the text refer to the diagrams
on pages 2-3.
Read the operating instructions carefully
before using this device. Familiarise
yourself with its functions and basic
operation. Service the device as per the
instructions to ensure that it always
functions properly. The operating
instructions and the accompanying
documentation must be kept in the
vicinity of the device.
Contents
1. Machine information
2. Safety instructions
3. Mounting accessories
4. Operation
5. Service & maintenance
1. Machine information
Technical specifications
Voltage
Charger voltage
Charger frequency
Battery capacity
Charging time
Max. torque
No-load speed
Chuck capacity
Weight (incl. battery)
Lpa (acoustic pressure)
Lwa (acoustic power)
Vibration value
4
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in EN
60745; it may be used to compare one tool with
another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned
-
-
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns
Contents of packing
1
2
1
1
1
1
1
Check the appliance, any loose parts and
accessories for damage caused during transport.
Product information
Fig. A
1. On/off switch
2. Torque setting ring
18 V
3. Chuck
230 V
4. Battery
50 Hz
5. Direction switch
1.0 Ah
3-5 hours
16 Nm
0-550/min
Explanation of the symbols
0.8-10 mm
1.68 kg
70.5+3dB(A)
81.5+3dB(A)
Ah=3.12 m/s² K=1.5m/s²
using the tool for different applications, or with
different or poorly maintainted accessories,
may significantly increase the exposure level
the times when the tool is switched off or when
it is running but not actually doing the job, may
signifi cantly reduce the exposure level
Cordless drill
Batteries
Adapter + battery holder
Double-sided bits
Operating instructions
Safety instructions
Warranty card
2. Safety instructions
Denotes risk of personal injury, loss of
life or damage to the tool in case of non-
observance of the instructions in this
manual.
Indicates electrical shock hazard.
