INSTRUCTION MANUAL
1.5. EXTENSION OPTIONS & ACCESSORIES
Extension option: You have the possibility of extending your computer
with the cadence extension set
In this case the following cadence functions are available to you:
Actual cadence
Average cadence
Maximum cadence
ORIGINAL
In addition you can also get the following original VDO
EQUIPMENT
replacement parts from your dealer
Designation
Universal handlebar holder - wireless
Magnet S/M for speed impulses
Magnet L/XL for speed impulse
Cadence magnet
Speed transmitter
Pulse transmitter (incl. elastic chest belt)
Elastic chest belt for pulse transmitter article
Replacement docking station
Cadence kit
Wrist band
Wrist band lock
Universal mount kit
When purchasing look for the VDO Cyclecomputing original equipment
logo. Only products bearing this logo are authorized by VDO Cyclecom-
puting for use with your computer.

2. INSTALLATION

2.1. BATTERY INSTALLATION

2.1.1 BATTERY INSTALLATION - COMPUTER AND SPEED/CADENCE
article number
TRANSMITTER
step 1 Insert the battery into the computer/transmitter housing with
art. no. 5503
the + pole up.
art. no. 4410
step 2 Ensure that the battery is not tilted.
step 3 Ensure that the rubber seal lies smoothly on the lid of the
art. no. 4412
battery compartment.
art. no. 4411
step 4 Insert the battery compartment lid into the opening and use
a coin to firmly turn the battery door to right until the stop
art. no. 6602
(approximately 1/3 turn)
TIP for changing batteries: VDO recommends changing the batteries
art. no. 6605
yearly to avoid undesired data loss. Thus strictly ensure that you note
art. no. 6606
the entered wheel sizes as well as the previous ridden kilometers for
bike 1 & bike 2, as well as the total altitude difference for bike 1, bike
>>> P02
art. no. 6609
art. no. 6603
art. no. 6607
art. no. 6608
art. no. 6601
11
