Technical data ROCAM 4 Plus

Battery voltage ................................ 18 V DC
Battery capacity .............................. 2,0 Ah / 4,0 Ah
Rated power consumption .............. 16 W
Working temperature ...................... -10 ... +50 °C
Storage temperature ....................... -30 ... +50 °C
Dimensions (L x W x H, mm) .......... 560 x 400 x 340
Weight (with battery) ....................... 18,6 kg / 22,4 kg (30m/ 65m slide cable length)
Monitor ........................................... Touchscreen 10.4"
Picture/Video format ....................... JPG / AVI (resolution 720px. x 600px.)
Video Out ....................................... Micro HDMI
Memory capacity.......................... ut 4 GB SD-card (max. 32 GB)
Camera module .............................. CMOS colour PAL
Camera head diameter ................... ø 30 mm, ø 40 mm (optional ø 25 mm Mini Modul)
Slide cable length ........................... 30 m / 65 m (optional 8 m Mini Modul)
Slide cable diameter ....................... ø 7.0 mm / ø 8.0 mm (optional ø 5,5 mm Mini Modul)
Working range ................................ Ø 40 - 100 mm (optional Mini Modul)
Positioning transmitter .................... 33 kHz (bolt-on optional)
Protection class camera head ......... IP 68
Included in delivery: ROCAM 4 Plus TV- inspection system with Camera head ø30 mm or ø40
mm, guide ball, positioning transmitter 33 kHz, USB cable, test adaptor, manual, 4 GB SD card,
battery and charger.
2.1

Technical Data RO BC14/36 Charger, RO BP18/2 and RO BP18/4 battery

Battery, art.-no.: 2,0Ah 1000001652 /
4,0 Ah 1000001653
Typ/ model ...................................... RO BP18/2
Voltage ........................................... 18 V DC
Capacity ......................................... 2,0 Ah / 4,0 Ah
Charging voltage............................. 20,75 V DC
Charge current ................................ 4A / 8A
Charging temperature ..................... 0° - 46° C
Max. discharging temperature. ........ -15°C +75°C
Approx. charging time (90% full) ..... ca. 40 / 80 min.
Weight ............................................ ca. 400 / 670g
Recharge battery pack before first use!
26
Ø 70 - 150 mm (30 mm camera head)
Ø 100 - 300 mm (40 mm camera head)
Charger, art. no.: EU 1000001654 /
AUS 1000001655 / USA CND 1000001656/
UK 1000001691
Typ/ model ........................................
RO BP18/4
Li-Ion Battery
Input voltage .....................................
Input frequency .................................
Input power .......................................
Charging voltage ...............................
Max. charge current ..........................
Rated output .....................................
No. of battery cells ............................
Weight ..............................................
ENGLISH
RO BC14/36
Charger for 18V Li-
Ion Akku
220V – 240V AC /
100 – 120´V AC
50 – 60 Hz
85 W
12-42V DC
3A
68 W
4-10
ca. 600 g
Pay attention to the electrical outlet
voltage! Check the label on the
bottom of the charger!
