EN
26
BUTTON 3
BUTTON 4
BUTTON 5
For air device: with key 5 you set the SET POWER (see Chapter 4).
For hydro device: with key 5 you set the AIR FAN parameter (if present on the device, see Chapter 7). With a
long press they read the temperature and water pressure in the boiler.
BUTTON 6
For air and hydro device: with key 6 you set the SET POWER (see Chapter 4); with a long press gives access
to informations reserved to authorized technician.

3. POWER

Before performing the first switch, refer to section 20 FIRST START.
To turn on the unit, press on P4 for a few seconds. The successful ignition is indicated in the display with the
message as shown here down. This phase has a duration set by the manufacturer and is not editable. Under these
conditions, the unit remains in a warm state, the lighter il hot (shown by the LED lighter ) and the fan smoke
extraction run. Any anomalies during the ignition phase, are shown on the display and the unit goes into an alarm
state. (refer to chapter MALFUNCTION)
LIGHTING
Load pellet
After 1 minute approx on the display you see:
WAIT PREHEAT
After the pellet start to fall in the burner , on the display you see:
PELLET LOAD
Fire
After the flue gas temperature has reached and exceeded the default from the manufacturer, the system switches to
power mode display "Fire On" on the display.
Any anomalies, stop the card and indicates the error status (refer to chapter MALFUNCTION).
FIRE ON
-
Menù
MENU'
Programmations
Work / Off
ON / OFF
unlock Lock
Menù / Programmations
Work / Off
Reduce
Menù
POWER
Programmations
Work / Off
Increase
Menù
POWER
Programmations
REMOTE CONTROL
Access the MENU
Accesses the next level of
submenus
Set value and moves to the next
menu item
Hold for 2 seconds turns on or off
the unit if it is
OFF or ON, respectively
Unlock the device and brings it back
in power off state
It leads to higher menu level, the
changes are stored
Decreases the value of the output
power of the stove / Air fan
Moves to the next menu item
Go to the next sub-menu item, the
changes are stored
Increases the value of the output
power of the stove / Air fan
Go to the previous menu
Moves to the previous submenu
item, the changes are stored
