Use
Handling objective
All radio probes:
1
Open battery compartment
(Probe must be switched off.)
2
a) Installing / changing batteries:
b) De/activate AutoOff function:
c) Set probe ID index:
3
Close battery compartment:
Switch on (Transmission rate 0.5s):
-or-
Switch on (transmission rate 10s):
Switch off:
Modular handgrip only:
1
Remove probe module
(Probe must be switched off):
2
Install probe module:
Battery condition display
LED colour Condition
blue Battery OK
red Battery nearly empty
Contact
www.testo.com
Handling steps / result
Unscrew the screw on the underside and pry loose the battery compartment cover
using the lifting tab as illustrated on the cover.
Remove spent batteries (if installed), and place new batteries in the battery com
partment (Modular radio probe: 2x Micro AAA, other radio probes: 2x CR2032).
Observe polarity, see instructions in battery compatment!
The AutoOff function is only active at a tranmission rate of 0.5s.
Set dip switch 1 (top left in the battery compartment:
On
: Function is on, probe switches off automaticalyl after 60 min.
0ff
: Function is off, probe does not switch off automatically.
Set dip swirch 2 (top left in the battery compartment):
On H
: Index
Off L
: Index
Replace battery compartment cover and fix with screw.
Briefly press .
- LED lights up for 2s and then blinks every 2s.
- Measurement value transmission every 0.5s.
Hold down until LED lights up.
- LED lights up for 2s and then blinks every 10s.
- Measurement value transmission every 10s.
Hold down until LED blinks 4 times.
- Probe switches off.
Unscrew locking cap on the head of the handgrip and remove probe module (if
installed).
Attach probe module to the handgrip and screw on relevant locking cap.
