Page GB-22 Changing the door hinges
6. Unscrew the middle hinge and remove
it. Pay attention to the plastic discs (14).
They must later be repositioned correctly
in the same place.
7. Open the lower door, take it out and set it
aside.
(15)
8. Move the blind plug (15) on the top of the
lower door to the opposite side.
(14)
10. Tilt the unit slightly backwards against a
11. Remove the screw feet (5) on both
12. Unscrew the hinge (18).
13. Replace the hinge bolt as shown above.
(16)
9. Unscrew the two blind plugs (16) and re-
insert them on the opposite side.
wall so that the lower hinge (18) is ac-
cessible.
sides.
(17)
(18)
(18)
(5)
